TLE nozzles

1000 Bar
TLE nozzles

Product description

TLE nozzles in different sizes - connections to use on lance machines.

Perfect cleaning quality, nozzles are all tangential drilled (out of center).

Parallel threads (BSP-Metric) flat bottom

  • 1/16"NPTF ø 9,5 x 20 P/N : 15-351-004
  • M7x1F ø 9,5 x 25 P/N : 15-351-001 (1500 Bar max. wp)
  • ⅛"NPTF ø 11,8 x 25 mm. P/N : 15-351-005
  • ⅛"BSPF ø 12 x 30 mm. P/N : 15-351-002 (1500 Bar max. wp)
  • ¼"NPTF ø 15,9 x 30 mm. P/N : 15-351-006
  • ¼"BSPF ø 15,9 x 35 mm. P/N : 15-351-003 (1500 Bar max. wp)


  • All nozzles same pattern (open "document") : 1@A(0°) - 4@C1(90°) - 4@C2(90°)
  • First two nozzles mark with * : drilled all 9 x ø 0,60 mm.
  • Rest of the nozzles drilled ø 0,50 mm. front (A) rest 8 x ø 0,60 mm.


Copper washers for BSP - Metric thread click here
