Ceramic Fan Jet nozzles M10x1M 40°

Product description

M10x1 Fan Jet 40°

If you want a better life time out of your steel fan jets, you can use the Ceramic Fanjet, the ceramic is protected in a stainless steel body.

Those nozzles can also be used for surface cleaning but also for sewer cleaning on recycling trucks by mounting the nozzles in bombs and granates.

Technical details :

• Dimensions : Hex. 10 mm. length :13,5 mm.
• Material body : st. st. 303 material insert : ceramic
• Max. temp. : 125°C
• Nozzle number : 40040 P/N : 1520.120
• Nozzle number : 40075 P/N : 1520.160
• Nozzle number : 40100 P/N : 1520.190

To calculate the correct nozzle you can use attached Nozzle chart, for example : 150 bar - 20 ltr. nozzle number 40075, please note, this chart is approximate, so it can be a little different in practice

• If you need the right tool for the right job, please use tool number 2950ST10 click here for more information
• you also can use Socket wrench with cross handle 8023, for more information click here
• Blindplug : Hex.10 mm , length 13,5 mm. P/N : 4207

To disassemble an old insert it's recommended to heat the nozzle a little so the glue melts, clean the thread and glue the new insert with a drop of blue loctite 243, more info click here
