9/16"MPLH - ¼"NPT

Product description

Slimline couplers mostly use to connect lances, by using slimline couplers the OD of the connection is the smallest.

For easy connection there are 2 flat sides, to avoid "sticking" in a tube they are 30° chamfered on each side.

To get more support on both ends there is a small chamber for the connection for supporting the lance.

• Dimensions : ø 19 x 57 mm.
• Connection : 9/16"-18UNF LH - ¼"NPT
• Material : exotic st. st. incl. heat treatment
• Part number : 20-027-003
