⅛"BSP - ⅛"BSP
1500 Bar
Product description
Slimline couplers mostly use to connect lances (stingers) ,by using slimline couplers the OD of the connection is the smallest.
For easy connection there are 2 flat sides, to avoid "sticking" in a tube they are 30° chamfered on each side.
To get more support on both ends there is a small chamber for the connection for supporting the lance.
- Dimensions : ø 12 x 36 mm.
- ID : ø 3,5 mm.
- Connection : 2 x ⅛"BSP
- Material : st. st. 316
- Part number : 195-030
More information click on "drawing"
All our adapters are unselective tested,
When we receive adapters at least two of them will be tested at least 1.3 x working pressure on attached pdf file (click on cetificate) you will find test certificate of this adapter who is tested at 2000 Bar
BSP female thread is flat bottom, to get the perfect sealing between the hose / stinger / lance , you need a perfect fit copper washer.
- Copper washer ⅛"BSP Part number : 584.18
