M24x1,5
1600 Bar
Product description
Blind caps with cone are mostly used to blind of outlet connection of the high pressure unit that not being used.
- Dimensions : Hex. 30 x 32 mm.
- Material : st. st. 316
- Complete with 24° coned plug and o-ring
- Part number complete : 304057
- (Compatible Hammelmann® 00.01898.0003 )
Spare parts :
- Hex blind nut (body) M24x1,5 Part number : 304057.1
- M24x1,5 Cone plug M16x1M excl. O-ring Part number : 304055.3
- O-ring (Viton blue) M24 cone : 98000719blue
- Copper ring between M16 cone and body < 1000 Bar : 584.10
- Ampco ring between M16 cone and body > 1000 Bar : 584.17.ALB
- Cone 304055.3 mounting with Alan Key 10 mm. and Loctite 270
