M7F - M24x1,5M

Product description

Adapter various applications, mostly connecting flex hose to main DN4/12 hose with M24x1,5 swivel nut.

• Connections : M7x1F (flat bottom) - M24x1,5M (hose)
• Dimensions : hex. 27 x 40 mm.
• ID ø 3 mm.
• Material : st. steel 316 (Chemical resistant)
• Part number : 304981

Open attached drawing for more details

Copper washer M7 flat, please use 584.07 click here

Documents

• Drawing 304981
