Hose Guide Ladyfinger

Product description

Hose guide tube model suitable for hoses up to 1¼"

One of the oldest hose protecting device on the market, both ends POM wearing sleeves, rest is complete made of stainless steel, stained and passivated,

Option for this type "Ladyfinger" is a cleaning device that can placed on the inlet, so that the hose cna be cleaned on the outside during rolling up by 12 M6 nozzles with a ½"BSP connection

Technical details :

• Total length included wearing sleeves : 500 mm.
• OD Wearing Sleeves : ø 135 mm.
• Smallest ID wearing sleeves : ø 60 mm.
• Total weight (included chain) : 9 kg.
• Hose guide complete Part number : 1630

Same as above , included nozzle ring (12 x M6 nozzles) on inlet ½"BSP connection :

• Total length included wearing sleeves : 530 mm.
• OD Wearing Sleeves : ø 135 mm.
• Smallest ID wearing sleeves : ø 60 mm.
• Total weight (included chain) : 13 kg.
• Hose guide complete Part number : 1630-S

• Spare chain ± 7 mtr. st.st. 316 Part number : 1018650.7000
• Carbiner ø 8 mm. st. steel Part number : 24518
