UHP Hose with swivel fitting

Product description

Very compact UHP Swivel fitting , rotation under pressure

• Biggest OD = 36 mm.
• Length of the hose at choice
• Available in various connections
• Swivel fitting mounted straight into the inlet gun
• Mostly use as leader hose of ± 2.5 mtr. in combination with the safety shroud (leave this combination mounted on the gun)

DN5 UHP hose length 2.5 mtr.

• M26x1,5M Swivel - M14x1,5LHM Part number : 2.5M-2794DN5-M26SM14
• M30x2M Swivel- M14x1,5LHM Part number : 2.5M-2794DN5-M30SM14
• 1-1/8"UNFM Swivel - 9/16'-18LHM. Part number : 2.5M-2794DN5-UNF9S6CT

DN8 UHP hose length 2.5 mtr.

• M26x1,5M Swivel - M14x1,5LHM Part number : 2.5M-2794DN8-M26SM14
• M30x2M Swivel- M14x1,5LHM Part number : 2.5M-2794DN8-M30SM14
• 1-1/8"UNFM Swivel - 9/16'-18LHM. Part number : 2.5M-2794DN8-UNF9S6CT
