2822 series (49° seal)

Product description

Standard grade "short-stem" insert-style sapphire waterjet orifice assembly used in abrasive or pure water cutting and blasting applications.

• diameter head ø 9,5 mm. (.375")
• 49° sealing angle
• working pressure up to 4200 bar (60K).
• orifice sizes .004” till .050” (ø 0,10 mm. - ø 1,27 mm.)

Part number plug: 2939-0

• Hammelmann® type: F
