3604 series (7/16"-20UNF)

Product description

Standard sapphire waterjet orifice assembly designed for use in blasting applications.

StoneAge © BC-H9-C Barracuda Gun nozzle, Scimitar©40K,

Produces a coherent waterjet stream to minimize energy loss.

• Thread : 7/16-20UNF
• Hex head : 7/16"
• Orifice sizes .004" - .050" ( 0,10 mm. tot 1,27 mm.)
•  Part number : 3604-.. ( so ø .010" = ø 0,25 mm. P/N : 3604-10)

• Part number plug: 3108

• Stocket wrench with cross handle Part number : 60070.1065

StoneAge© type : OS7™
